기능과 목적에 따른 리습 문장 예제 입니다



참고하여 자신에게 맞게 리습을 작성바랍니다



링크는 상세 설명 페이지 입니다

기능 목적 예제문
각도 정의 (두점)
https://autocadlisp.tistory.com/4
(setq p10 (polar p1 ang d))
각도 환산 라디안 도
https://autocadlisp.tistory.com/5
( angtos 0.785398 0 4)
문자를 실수로 변환
https://autocadlisp.tistory.com/6
(atof abc)
실수를 소숫점이 없는 실수로 변환하기
https://autocadlisp.tistory.com/7
(setq dre (fix dre) dre (float dre))
실수를 정수로 변환
https://autocadlisp.tistory.com/7
(setq dre (fix dre) dre (float dre))
알림창 띄우기
https://autocadlisp.tistory.com/3
 (setq mesg
(strcat " Pulley1= Ø" (rtos dl 2 2) "   Pulley2= Ø" (rtos ds 2 2) "   Distance of Center= " (rtos cen 2 2) "  Belt length= " (rtos Len 2 2) "  " )
 (alert mesg)
오스냅 제어
https://autocadlisp.tistory.com/2
(setq osm (getvar "osmode"))
(setvar "osmode" 0 )
(그리기나 삽입 실행 문장)

(setvar "osmode" osm)
정수를 실수로 변환
https://autocadlisp.tistory.com/8
(setq dre (fix dre) dre (float dre))
